多变量逆解耦自抗扰控制及其在精馏塔过程中的应用

程赟 陈增强 孙明玮 孙青林

程赟, 陈增强, 孙明玮, 孙青林. 多变量逆解耦自抗扰控制及其在精馏塔过程中的应用. 自动化学报, 2017, 43(6): 1080-1088. doi: 10.16383/j.aas.2017.c170137
引用本文: 程赟, 陈增强, 孙明玮, 孙青林. 多变量逆解耦自抗扰控制及其在精馏塔过程中的应用. 自动化学报, 2017, 43(6): 1080-1088. doi: 10.16383/j.aas.2017.c170137
CHENG Yun, CHEN Zeng-Qiang, SUN Ming-Wei, SUN Qing-Lin. Multivariable Inverted Decoupling Active Disturbance Rejection Control and Its Application to a Distillation Column Process. ACTA AUTOMATICA SINICA, 2017, 43(6): 1080-1088. doi: 10.16383/j.aas.2017.c170137
Citation: CHENG Yun, CHEN Zeng-Qiang, SUN Ming-Wei, SUN Qing-Lin. Multivariable Inverted Decoupling Active Disturbance Rejection Control and Its Application to a Distillation Column Process. ACTA AUTOMATICA SINICA, 2017, 43(6): 1080-1088. doi: 10.16383/j.aas.2017.c170137

多变量逆解耦自抗扰控制及其在精馏塔过程中的应用

doi: 10.16383/j.aas.2017.c170137
基金项目:

天津市自然科学基金 14JCYBJC18700

国家自然科学基金 61573197

国家自然科学基金 61573199

详细信息
    作者简介:

    程赟 南开大学博士研究生.主要研究方向为自抗扰控制.E-mail: 1120160118@mail.nankai.edu.cn

    孙明玮 南开大学教授.主要研究方向为飞行器制导与控制, 自抗扰控制.E-mail: smw_sunmingwei@163.com

    孙青林 南开大学教授.主要研究方向为自适应控制, 柔性航空器建模与控制. E-mail: sunql@nankai.edu.cn

    通讯作者:

    陈增强 南开大学教授.主要研究方向为自抗扰控制, 预测控制. E-mail: chenzq@nankai.edu.cn

Multivariable Inverted Decoupling Active Disturbance Rejection Control and Its Application to a Distillation Column Process

Funds:

the Natural Science Foundation of Tianjin 14JCYBJC18700

National Natural Science Foundation of China 61573197

National Natural Science Foundation of China 61573199

More Information
    Author Bio:

    Ph. D. candidate at Nankai University. His main research interest is active disturbance rejection control

    Professor at Nankai University. His research interest covers guidance and control for flight aircraft and active disturbance rejection control

    Professor at Nankai University. His research interest covers self-adaptive control, modeling and controlling of flexible spacecraft

    Corresponding author: CHEN Zeng-Qiang Professor at Nankai University. His research interest covers active disturbance rejection control and predictive control. Corresponding author of this paper
  • 摘要: 化工生产是一类典型的多变量过程对象,该类对象具有时变性、耦合性、时滞性等特点,传统的单变量控制方法很难在此类系统中取得良好的控制效果.针对时变性,本文在假设对象模型未知的前提下,利用阶跃响应数据,研究了基于最小二乘的一阶、二阶时滞系统辨识方法.针对多变量系统存在耦合性的特点,采用逆解耦方法实现对象的解耦.再对解耦后的时滞子系统设计了自抗扰控制器.仿真实验中,以精馏塔的Wood-Berry模型和Ogunnaike-Ray模型为例,验证了算法的有效性.
    1)  本文责任编委 王伟
  • 图  1  TITO系统逆解耦器结构图

    Fig.  1  Inverted decoupling structure of TITO system

    图  2  三种方法跟踪轨迹以及抗扰性能

    Fig.  2  Tracking and disturbance rejection performance of three methods

    图  3  采用NSR=1 %下辨识数据控制效果

    Fig.  3  Control efiect by using identiflcation data of NSR=1%

    图  4  采用NSR=10 %下辨识数据控制效果

    Fig.  4  Control efiect by using identiflcation data of NSR=10 %

    图  5  三种方法跟踪轨迹以及抗扰性能

    Fig.  5  Tracking and disturbance rejection performance of three methods

    图  6  采用NSR=1 %下辨识数据控制效果

    Fig.  6  Control efiect by using identiflcation data of NSR=1 %

    图  7  采用NSR=10 %下辨识数据控制效果

    Fig.  7  Control efiect by using identiflcation data of NSR=10 %

    表  1  Wood-Berry模型辨识结果的均方误差

    Table  1  Mean square error of the Wood-Berry model

    G11G12G21G22
    NSR=1%1.93×10-46.37×10-52.98×10-54.69×10-5
    NSR=10%4.88×10-56.32×10-46.62×10-42.10×10-3
    下载: 导出CSV

    表  2  三种算法IAE指标对比

    Table  2  Comparison of IAE for three methods

    IAE1IAE2Sum
    3-ADRC6.0115.1521.16
    ID-ADRC5.2521.0926.34
    ID-TDADRC2.598.7711.36
    下载: 导出CSV

    表  3  采用辨识数据控制下的IAE指标

    Table  3  IAE by using identiflcation data

    IAE1IAE2Sum
    NSR=1%2.628.7811.40
    NSR=10%2.738.7711.50
    下载: 导出CSV

    表  4  三种算法IAE指标对比

    Table  4  Comparison of IAE for three methods

    G11G12G13G21G22G23G31G32G33
    NSR=1%1.62×10-75.19×10-77.08×10-123.63×10-61.94×10-61.07×10-105.60×10-44.69×10-51.38×10-6
    NSR=10%2.36×10-81.35×10-61.95×10-101.61×10-63.45×10-63.12×10-102.70×10-32.00×10-32.38×10-4
    下载: 导出CSV

    表  5  三种算法IAE指标对比

    Table  5  Comparison of IAE for three methods

    IAE1IAE2IAE3Sum
    3-ADRC15.2223.4119.2357.86
    ID-ADRC17.7510.6535.1663.56
    ID-TDADRC4.595.418.8618.86
    下载: 导出CSV

    表  6  采用辨识数据控制下的IAE指标

    Table  6  IAE by using identiflcation data

    IAE1IAE2IAE3Sum
    NSR=1%4.615.5017.8527.96
    NSR=10%4.635.5538.1548.33
    下载: 导出CSV
  • [1] Wood R K, Berry M W. Terminal composition control of a binary distillation column. Chemical Engineering Science, 1973, 28(9): 1707-1717 doi: 10.1016/0009-2509(73)80025-9
    [2] Rake H. Step response and frequency response methods. Automatica, 1980, 16(5): 519-526 doi: 10.1016/0005-1098(80)90075-8
    [3] Unbehauen H, Rao G P. Identification of Continuous Systems. Amsterdam, Netherlands: North-Holland, 1987.
    [4] Gustavsson I. Survey of applications of identification in chemical and physical processes. Automatica, 1975, 11(1): 3-24 doi: 10.1016/0005-1098(75)90005-9
    [5] Wang Y G, Cai W J, Ge M. Decentralized relay-based multivariable process identification in the frequency domain. IEEE Transactions on Automatic Control, 2003, 48(5): 873-878 doi: 10.1109/TAC.2003.811271
    [6] Bi Q, Cai W J, Lee E L, Wang Q G, Hang C C, Zhang Y. Robust identification of first-order plus dead-time model from step response. Control Engineering Practice, 1999, 7(1): 71-77 doi: 10.1016/S0967-0661(98)00166-X
    [7] Wang Q G, Zhang Y. Robust identification of continuous systems with dead-time from step responses. Automatica, 2001, 37(3): 377-390 doi: 10.1016/S0005-1098(00)00177-1
    [8] Wang Q G, Guo X, Zhang Y. Direct identification of continuous time delay systems from step responses. Journal of Process Control, 2001, 11(5): 531-542 doi: 10.1016/S0959-1524(00)00031-7
    [9] Ahmed S, Huang B, Shah S L. Identification from step responses with transient initial conditions. Journal of Process Control, 2008, 18(2): 121-130 doi: 10.1016/j.jprocont.2007.07.009
    [10] Zhu Y C, Patwardhan R, Wagner S, Zhao J. Toward a low cost and high performance MPC: the role of system identification. Computers & Chemical Engineering, 2013, 51(14): 124-135
    [11] Van Overschee P, De Moor B L. Subspace identification for linear systems: theory-implementation-applications. US: Springer, 1996.
    [12] Lee J H. Model predictive control: review of the three decades of development. International Journal of Control, Automation and Systems, 2011, 9(3): 415-424 doi: 10.1007/s12555-011-0300-6
    [13] 席裕庚, 李德伟, 林姝.模型预测控制—现状与挑战.自动化学报, 2013, 39(3): 222-236 http://www.aas.net.cn/CN/abstract/abstract17874.shtml

    Xi Yu-Geng, Li De-Wei, Lin Shu. Model predictive control: status and challenges. Acta Automatica Sinica, 2013, 39(3): 222-236 http://www.aas.net.cn/CN/abstract/abstract17874.shtml
    [14] 杨剑锋, 赵均, 钱积新, 牛健.一类化工过程多变量系统的自适应非线性预测控制.化工学报, 2008, 59(4): 934-940 http://www.cnki.com.cn/Article/CJFDTOTAL-HGSZ200804023.htm

    Yang Jian-Feng, Zhao Jun, Qian Ji-Xin, Niu Jian. Adaptive nonlinear model predictive control for a class of multivariable chemical processes. Journal of Chemical Industry and Engineering (China), 2008, 59(4): 934-940 http://www.cnki.com.cn/Article/CJFDTOTAL-HGSZ200804023.htm
    [15] Wade H L. Inverted decoupling: a neglected technique. ISA Transactions, 1997, 36(1): 3-10 doi: 10.1016/S0019-0578(97)00008-6
    [16] Luan X L, Chen Q, Albertos P, Liu F. Compensator design based on inverted decoupling for non-square processes. IET Control Theory & Applications, 2017, 11(7): 996-1005
    [17] Garrido J, Vázquez F, Morilla F. An extended approach of inverted decoupling. Journal of Process Control, 2011, 21(1): 55-68 doi: 10.1016/j.jprocont.2010.10.004
    [18] Garrido J, Vázquez F, Morilla F, Hägglund T. Practical advantages of inverted decoupling. Proceedings of the Institution of Mechanical Engineers, Part Ⅰ: Journal of Systems and Control Engineering, 2011, 225(7): 977-992 https://lup.lub.lu.se/search/publication/2223536
    [19] Garrido J, Vázquez F, Morilla F. Inverted decoupling internal model control for square stable multivariable time delay systems. Journal of Process Control, 2014, 24(11): 1710-1719 doi: 10.1016/j.jprocont.2014.09.003
    [20] Sun L, Dong J Y, Li D H, Lee K Y. A practical multivariable control approach based on inverted decoupling and decentralized active disturbance rejection control. Industrial & Engineering Chemistry Research, 2016, 55(7): 2008-2019 doi: 10.1021/acs.iecr.5b03738
    [21] 韩京清.自抗扰控制器及其应用.控制与决策, 1998, 13(1): 19-23 http://cdmd.cnki.com.cn/Article/CDMD-10532-2009164398.htm

    Han Jing-Qing. Auto-disturbance-rejection controller and its applications. Control and Decision, 1998, 13(1): 19-23 http://cdmd.cnki.com.cn/Article/CDMD-10532-2009164398.htm
    [22] Zheng Q, Gao Z Q. Active disturbance rejection control: between the formulation in time and the understanding in frequency. Control Theory and Technology, 2016, 14(3): 250-259 doi: 10.1007/s11768-016-6059-9
    [23] Zheng Q, Chen Z Z, Gao Z Q. A dynamic decoupling control approach and its applications to chemical processes. In: Proceedings of the 2007 American Control Conference (ACC'07). New York, USA: IEEE, 2007. 5176-5181
    [24] 张园, 孙明玮, 陈增强.强制循环蒸发系统线性自抗扰解耦控制的鲁棒设计.化工学报, 2015, 66(S2): 263-270 doi: 10.11949/j.issn.0438-1157.20141914

    Zhang Yuan, Sun Ming-Wei, Chen Zeng-Qiang. Robust design of linear active disturbance rejection decoupling control for forced-circulation evaporation system. CIESC Journal, 2015, 66(S2): 263-270 doi: 10.11949/j.issn.0438-1157.20141914
    [25] Tian L L, Li D H, Huang C E. Decentralized controller design based on 3-order active-disturbance-rejection-control. In: Proceedings of the 10th World Congress on Intelligent Control and Automation (WCICA). Beijing, China: IEEE, 2012. 2746-2751
    [26] 王丽君, 李擎, 童朝南, 尹怡欣.时滞系统的自抗扰控制综述.控制理论与应用, 2013, 30(12): 1521-1533 http://www.cnki.com.cn/Article/CJFDTOTAL-KZLY201312008.htm

    Wang Li-Jun, Li Qing, Tong Chao-Nan, Yin Yi-Xin. Overview of active disturbance rejection control for systems with time-delay. Control Theory & Applications, 2013, 30(12): 1521-1533 http://www.cnki.com.cn/Article/CJFDTOTAL-KZLY201312008.htm
    [27] Zhao S, Gao Z Q. Modified active disturbance rejection control for time-delay systems. ISA transactions, 2014, 53(4): 882-888 doi: 10.1016/j.isatra.2013.09.013
    [28] Zheng Q L, Gao Z Q. On active disturbance rejection for systems with input time-delays and unknown dynamics. In: Proceedings of the 2016 American Control Conference (ACC). Boston, USA: IEEE, 2016. 95-100
    [29] 唐德翠, 高志强, 张绪红.浊度大时滞过程的预测自抗扰控制器设计.控制理论与应用, 2017, 34(1): 101-108 http://www.cnki.com.cn/Article/CJFDTOTAL-KZLY201701013.htm

    Tang De-Cui, Gao Zhi-Qiang, Zhang Xu-Hong. Design of predictive active disturbance rejection controller for turbidity. Control Theory & Applications, 2017, 34(1): 101-108 http://www.cnki.com.cn/Article/CJFDTOTAL-KZLY201701013.htm
    [30] Gao Z Q. Scaling and bandwidth-parameterization based controller tuning. In: Proceedings of the 2003 American Control Conference. Denver, USA: IEEE, 2003. 4989-4996
    [31] Zheng Q, Gao L Q, Gao Z Q. On stability analysis of active disturbance rejection control for nonlinear time-varying plants with unknown dynamics. In: Proceedings of the 46th IEEE Conference on Decision and Control. New Orleans, USA: IEEE, 2007. 3501-3506
    [32] 陈增强, 孙明玮, 杨瑞光.线性自抗扰控制器的稳定性研究.自动化学报, 2013, 39(5): 574-580 http://www.aas.net.cn/CN/abstract/abstract17868.shtml

    Chen Zeng-Qiang, Sun Ming-Wei, Yang Rui-Guang. On the stability of linear active disturbance rejection control. Acta Automatica Sinica, 2013, 39(5): 574-580 http://www.aas.net.cn/CN/abstract/abstract17868.shtml
  • 加载中
图(7) / 表(6)
计量
  • 文章访问数:  2440
  • HTML全文浏览量:  275
  • PDF下载量:  888
  • 被引次数: 0
出版历程
  • 收稿日期:  2017-03-13
  • 录用日期:  2017-05-26
  • 刊出日期:  2017-06-20
