数据与模型联合驱动的陶瓷材料晶粒分割

雷涛 李云彤 周文政 袁启斌 王成兵 张小红

雷涛, 李云彤, 周文政, 袁启斌, 王成兵, 张小红. 数据与模型联合驱动的陶瓷材料晶粒分割. 自动化学报, 2020, 46(x): 1−16 doi: 10.16383/j.aas.c200277
引用本文: 雷涛, 李云彤, 周文政, 袁启斌, 王成兵, 张小红. 数据与模型联合驱动的陶瓷材料晶粒分割. 自动化学报, 2020, 46(x): 1−16 doi: 10.16383/j.aas.c200277
Lei Tao, Li Yun-Tong, Zhou Wen-Zheng, Yuan Qi-Bin, Wang Cheng-Bing, Zahng Xiao-Hong. Grain segmentation of ceramic materials using data-driven jointing model-driven. Acta Automatica Sinica, 2020, 46(x): 1−16 doi: 10.16383/j.aas.c200277
Citation: Lei Tao, Li Yun-Tong, Zhou Wen-Zheng, Yuan Qi-Bin, Wang Cheng-Bing, Zahng Xiao-Hong. Grain segmentation of ceramic materials using data-driven jointing model-driven. Acta Automatica Sinica, 2020, 46(x): 1−16 doi: 10.16383/j.aas.c200277

数据与模型联合驱动的陶瓷材料晶粒分割

doi: 10.16383/j.aas.c200277
基金项目: 国家自然科学基金(61871259, 61811530325, 61976130)资助
详细信息
    作者简介:

    雷涛:陕西科技大学电子信息与人工智能学院教授, 2011年获得西北工业大学信息与通信工程专业博士学位, 主要研究方向为数字图像处理、模式识别与机器学习. 本文通信作者.Email: leitaoly@163.com

    李云彤:陕西科技大学电气与控制工程学院研究生, 2018年获得陕西科技大学自动化专业学士学位, 主要研究方向为数字图像处理.Email: yuntong_li@163.com

    周文政:陕西科技大学电气与控制工程学院研究生, 2017年获得重庆大学自动化专业学士学位, 主要研究方向为数字图像处理.Email: zhou_wenz@163.com

    袁启斌:陕西科技大学电子信息与人工智能学院副教授, 硕导, 2018年获西安交通大学电子科学与技术专业博士学位, 主要研究方向包括: 新型储能电介质材料与器件、柔性可穿戴材料与器件、材料微纳尺度结构解析等.Email: yuanqibin-sust@163.com

    王成兵:陕西科技大学材料科学与工程学院教授, 博导, 2008年获中国科学院兰州化学物理研究所物理化学专业博士学位, 主要研究方向为材料表面技术与涂层.Email: wangchengbing@gmail.com

    张小红:陕西科技大学文理学院教授, 2005年获得西北工业大学计算机软件与理论博士学位, 主要研究方向为模糊逻辑、粗糙集、不确定性数学、数据科学和人工智能.Email: hangxiaohong@sust.edu.cn

    通讯作者:

    陕西科技大学电子信息与人工智能学院教授, 2011年获得西北工业大学信息与通信工程专业博士学位, 主要研究方向为数字图像处理、模式识别与机器学习. 本文通信作者. Email: leitaoly@163.com

Grain Segmentation of Ceramic Materials Using Data-Driven Jointing Model-Driven

Funds: Supported by National Natural Science Foundation of P. R. China (61871259, 61811530325, 61976130)
More Information
    Corresponding author: LEI Tao Professor at the school of Electronic Information and Artificial Intelligence, Shaanxi University of Science and Technology. He received his PhD degree in Information and Communication Engineering from Northwestern Polytechnical University in 2011. His research interest covers image processing and artificial intelligence. Corresponding author of this paper
  • 摘要: 研究陶瓷晶粒尺寸分布对估计陶瓷样品的物理属性具有重要意义, 当前主要依赖人工方法测量晶粒尺寸, 由于晶粒形状不规则且大小不一, 因此人工方法测量效率低、误差大. 针对该问题, 提出一种数据与模型联合驱动的陶瓷材料晶粒分割算法. 该算法首先通过图像预处理解决材料表面反光导致的灰度不均匀问题; 其次利用本文提出的鲁棒分水岭变换实现图像中晶粒的预分割, 解决传统分水岭算法存在的过分割以及分割区域个数与轮廓精度难以平衡的问题; 最后根据本文提出的轻量级富卷积特征网络输出晶粒轮廓并利用该轮廓对预分割结果进行优化. 与主流图像分割算法相比, 提出的算法一方面利用鲁棒分水岭变换实现了更为准确的晶粒区域定位, 另一方面利用图像的低层与高层特征融合获取了更为精准的晶粒轮廓. 实验结果表明, 提出的算法不仅能够实现陶瓷材料晶粒尺寸的精准计算, 而且具有较高的计算效率, 为分析陶瓷材料物理属性提供了客观准确的数据.
  • 图  1  总体流程图, 其中, SE为结构边缘算法(Structured Edge, SE)[32]

    Fig.  1  Overall flow chart, where SE denotes edge detection algorithm based on structured forests

    图  2  原图与预处理结果对比, 预处理算法能有效解决陶瓷SEM图像的灰度不均匀问题(a)-(d)为原图 (e)-(h)为经过预处理的图像

    Fig.  2  Comparison of original and pre-processed images, the pre-processing algorithm can effectively solve the issue of uneven grayscale of ceramic SEM image (a)-(d) original images (e)-(h) pre-processed images.

    图  3  不同参数的MGR-WT对图像的分割结果对比, $ r $是用于梯度重建的圆形结构元半径

    Fig.  3  Segmentation result comparison using MRG-WT with different parameters, $ r $ is the radius of structural element for gradient reconstruction

    图  4  RWT与MGR-WT对陶瓷材料晶粒的分割结果对比 (a) 未去除小区域的形态学分水岭算法分割结果(b) MGR-WT分割结果 (c) RWT分割结果 (d) RWT和MGR-WT的分割结果与Ground Truth对比(b线表示RWT结果, g线表示MGR-WT结果, p线表示Ground Truth结果)

    Fig.  4  Comparison of the segmentation results of ceramic grains between RWT and MGR-WT (a) segmentation result using watershed transform without removing small areas (b) segmentation result using MGR-WT (c) robust watershed segmentation (RWT) result (d) comparison of the segmentation results of RWT and MGR-WT with Ground Truth (line b for RWT, line g for MGR-WT and line p for Ground Truth)

    图  5  基于RWT的图像分割结果, 分割后结果存在双线轮廓问题

    Fig.  5  Segmentation results obtained by RWT suffer from the problem of double line contour

    图  6  去除双线 (a) RWT分割结果(b) 对(a)去除双线的结果 (c) 去除双线前后的结果对比

    Fig.  6  Removing double lines (a) segmentation result using RWT (b) removing double line from (a) (c) comparison of (a) and (b)

    图  7  深度可分离卷积

    Fig.  7  Depthwise separable convolution

    图  8  LRCF网络结构图

    Fig.  8  LRCF network structure

    图  9  基于LRCF与分水岭变换的图像分割 (a) 基于LRCF的轮廓预测 (b) 基于LRCF的MGR-WT结果 (c)基于LRCF的分割结果与Ground Truth对比(y线表示Ground Truth)

    Fig.  9  Image segmentation using the combination of LRCF and watershed transform (a) contour prediction using LRCF (b) segmentation result using the combination of LRCF and MGR-WT (c)comparison segmentation results of LRCF-MGR-WT and Ground Truth (line y for Ground Truth)

    图  10  轮廓优化 (a) 优化前结果 (b) 优化后结果 (c) 优化前后与Ground Truth对比(图中p线为优化结果, g线为优化前结果, y线为Ground Truth)

    Fig.  10  Contour optimization (a) the result before optimization (b) optimized results (c) comparison among (a), (b) and Ground Truth(line p for optimization result, line g for optimization result, line y for Ground Truth)

    表  1  不同方法对陶瓷晶粒分割的性能指标对比(第一组实验, 未镀金的图像)

    Table  1  Performance comparison of different approaches for ceramic grain segmentation (the first group of experiments for unplated image)

    MethodsCV↑VI↓GCE↓BDE↓
    Liu’s-MGR [38]0.28893.42700.47427.3230
    Random Walker [39]0.35562.90030.140713.2147
    SLIC [14]0.35473.05240.439610.1678
    LSC [15]0.34552.88200.35637.5911
    Banerjee’s [30]0.59592.19920.20313.9182
    SE-MGR-WT [32]0.46802.38870.13645.0346
    SE-AMR-WT [40]0.82871.12800.11221.6261
    RCF-MGR-WT [23]0.66361.49520.09553.5651
    LRCF-RWT0.86970.87100.07631.6262
    下载: 导出CSV

    表  2  不同方法对陶瓷晶粒分割的性能指标对比(第二组实验, 镀金的图像)

    Table  2  Performance comparison of different approaches for ceramic grain segmentation (the second group of experiments for gilded image)

    MethodsCV↑VI↓GCE↓BDE↓
    Liu’s-MGR [38]0.26223.80530.35656.9440
    Random Walker [39]0.38232.95170.220216.4378
    SLIC [14]0.32793.09620.407011.3350
    LSC [15]0.33472.84180.32658.0651
    Banerjee’s [30]0.70351.71750.10522.7484
    SE-MGR-WT [32]0.79791.20310.10332.0565
    SE-AMR-WT [40]0.87570.99090.11101.2623
    RCF-MGR-WT [23]0.57711.76910.08954.8813
    LRCF-RWT0.92170.66990.06281.0201
    下载: 导出CSV

    表  3  人工测量晶粒尺寸结果(单位: 像素)

    Table  3  Grain sizes using manual method (Units: pixels)

    测量者1测量者2测量者3测量者4测量者5
    194.5589.1793.3994.2288.51
    290.92100.33105.3891.4899.91
    3107.50100.91102.0996.4989.91
    4101.6189.9192.0894.4293.38
    5108.31103.8895.16102.4593.52
    6112.51108.21112.34109.70107.84
    7101.85104.13102.8094.4089.73
    下载: 导出CSV

    表  4  不同方法对陶瓷晶粒尺寸的计算结果对比(单位: 像素)

    Table  4  Comparison of ceramic grain sizes using different approaches (Units: pixels)

    人工测量Ground TruthLiu’s-MGR [38]RW [39]SLIC [14]LSC [15]Banerjee’s [30]SE-MGR-WT [32]SE-AMR-WT [40]RCF-MGR-WT [23]LRCF-RWT
    192.2697.8088.00195.1674.3363.9592.5848.8883.7363.0798.56
    297.2498.0085.60161.5474.4863.6686.5955.0994.3475.0899.15
    399.8392.3382.81175.1576.6662.39105.2950.9290.5263.0892.47
    493.2993.3465.97206.9675.7262.7386.4553.1787.7065.2192.48
    5100.5096.0974.38192.8075.9968.04102.0267.2593.8759.9596.76
    6110.0898.9369.83177.5676.4870.01104.0876.3896.0059.31100.65
    799.6896.6178.18183.0375.5071.71114.2885.2993.9853.5997.67
    下载: 导出CSV

    表  5  不同方法计算陶瓷晶粒尺寸结果的误差(单位: 像素)

    Table  5  Error comparison of different approaches on ceramic grain size computation (Units: pixels)

    Liu’s-MGR [38]RW [39]SLIC [14]LSC [15]Banerjee’s [30]SE-MGR-WT [32]SE-AMR-WT [40]RCF-MGR-WT [23]LRCF-RWT
    1-9.80+97.36-23.47-33.85-5.22-48.92-14.07-34.73-0.76
    2-12.40+63.54-23.52-34.34-11.41-42.91-3.66-22.92+1.15
    3-9.52+82.82-15.67-29.94-12.96-41.41-1.81-29.25-0.14
    4-27.37+113.62-17.62-30.61-6.89-40.17-5.64-28.13-0.86
    5-21.71+96.71-20.1-28.05+6.07-28.84-2.22-36.14-0.67
    6-29.10+18.63-22.45-28.92+5.15-19.55-2.93-39.62+1.72
    7-18.43+86.42-21.11-24.90+17.67-11.32-2.63-43.02-1.06
    下载: 导出CSV
  • [1] Viola G, Chong K B, Eriksson M, Shen Z, Zeng J, Yin Q, et al. Effect of grain size on domain structures, dielectric and thermal depoling of Nd-substituted bismuth titanate ceramics. Applied Physics Letters, 2013, 103(18): 182903
    [2] Yuan Q, Yao F, Wang Y, Ma R, Wang H. Relaxor ferroelectric 0.9 BaTiO3–0.1 Bi (Zn0.5Zr0.5) O3 ceramic capacitors with high energy density and temperature stable energy storage properties. Journal of Materials Chemistry C, 2017, 5(37): 9552−9558
    [3] Yang Z, Gao F, Du H, Jin L, Yan L, Hu Q, et al. Grain size engineered lead-free ceramics with both large energy storage density and ultrahigh mechanical properties. Nano Energy, 2019, 58: 768−777
    [4] 邹耀斌, 雷帮军, 臧兆祥, 王俊英, 胡泽海, 董方敏. 归一化互信息量最大化导向的自动阈值选择方法. 自动化学报, 2019, 45(7): 1373−1385

    Zou Yao-Bin, Lei Bang-Jun, Zang Zhao-Xiang, Wang Jun-Ying, Hu Ze-Hai, Dong Fang-Min. Automatic threshold selection guided by maximizing normalized mutual information. Acta Electronica Sinica, 2019, 45(7): 1373−1385
    [5] Yang M, Liu S, Chen K, Zhang H, Zhao E, Zhao T. A hierarchical clustering approach to fuzzy semantic representation of rare words in neural machine translation. IEEE Transactions on Fuzzy Systems, 2020, 28(5): 992−1002
    [6] Lei T, Jia X, Zhang Y, He L, Meng H, Nandi A K. Significantly fast and robust fuzzy c-means clustering algorithms based on morphological reconstruction and membership filtering. IEEE Transactions on Fuzzy Systems, 2018, 26(5): 3027−3041
    [7] 陶新民, 王若彤, 常瑞, 李晨曦, 刘艳超. 基于低密度分割密度敏感距离的谱聚类算法. 自动化学报, 2020, 46(7): 1479−1495

    Tao Xin-Min, Wang Ruo-Tong, Chang Rui, Li Chen-Xi, Liu Yan-Chao. Low density separation density sensitive distance-based spectral clustering algorithm. Acta Electronica Sinica, 2020, 46(7): 1479−1495
    [8] 雷涛, 张肖, 加小红, 刘侍刚, 张艳宁. 基于模糊聚类的图像分割研究进展. 电子学报, 2019, 47(08): 1776−1791 doi: 10.3969/j.issn.0372-2112.2019.08.023

    Lei Tao, Zhang Xiao, Jia Xiao-Hong, Liu Shi-Gang, Zhang Yan-Ning. Research progress on image segmentation based on fuzzy clustering. Acta Electronica Sinica, 2019, 47(08): 1776−1791 doi: 10.3969/j.issn.0372-2112.2019.08.023
    [9] 马超, 刘亚淑, 骆功宁, 王宽全. 基于级联随机森林与活动轮廓的3D MR图像分割. 自动化学报, 2019, 45(5): 1004−1014

    Ma Chao, Liu Ya-Shu, Luo Gong-Ning, Wang Kuan-Quan. Combining concatenated random forests and active contour for the 3D MR images segmentation. Acta Electronica Sinica, 2019, 45(5): 1004−1014
    [10] Zhang L, Wu K T, Li P. An improved adaptive level set method for image segmentation. International Journal of Pattern Recognition & Artificial Intelligence, 2017, 32(5): 1854013
    [11] Liu X, Guo S, Yang B, Ma S, Fu Y. Automatic organ segmentation for CT scans based on super-pixel and convolutional neural networks. Journal of Digital Imaging, 2018, 31(6): 748−760
    [12] Zhang Z, Pan X, Cheng L, Zhan S, Zhou H, Chen R, et al. SAR image segmentation using hierarchical region merging with orientated edge strength weighted Kuiper’s distance. IEEE Access, 2019, 7: 84479−84496 doi: 10.1109/ACCESS.2019.2910735
    [13] Ghosh P, Mali K, Das S K. Use of spectral clustering combined with normalized cuts (N-Cuts) in an iterative k-means clustering framework (NKSC) for superpixel segmentation with contour adherence. Pattern Recognition and Image Analysis, 2018, 28(3): 400−409
    [14] Achanta R, Shaji A, Smith K, Lucchi A, Fua P, Süsstrunk, S. SLIC superpixels compared to state-of-the-art superpixel methods. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2012, 34(11): 2274−2282
    [15] Li Z, Chen J. Superpixel segmentation using linear spectral clustering. IEEE Transactions on Image Processing, 2017, 26(7): 3317−3330 doi: 10.1109/TIP.2017.2651389
    [16] Liu M Y, Tuzel O, Ramalingam S, Chellappa R. Entropy rate superpixel segmentation. In: Proceedings of IEEE Computer Vision and Pattern Recognition, CO, USA: IEEE, 2011. 2097-2104.
    [17] Zhao Z Q, Zheng P, Xu S, Wu X. Object detection with deep learning: A review. IEEE transactions on neural networks and learning systems, 2019, 30(11): 3212−3232 doi: 10.1109/TNNLS.2018.2876865
    [18] Wang K, Liew J H, Zou Y, Zhou D, Feng J. Panet: Few-shot image semantic segmentation with prototype alignment. In: Proceedings of International Conference on Computer Vision. Seoul, Korea: IEEE, 2019. 9197−9206.
    [19] Long J, Shelhamer E, Darrell T. Fully convolutional networks for semantic segmentation. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2014, 39(4): 640−651
    [20] He K, Zhang X, Ren S, Sun J. Spatial pyramid pooling in deep convolutional networks for visual recognition. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2015, 37(9): 1904−1916 doi: 10.1109/TPAMI.2015.2389824
    [21] Zhao H, Shi J, Qi X, Wang X, Jia J. Pyramid scene parsing network. In: Proceedings of IEEE Computer Vision and Pattern Recognition, Honolulu, USA: IEEE, 2017. 6230−6239.
    [22] Chen L C, Papandreou G, Kokkinos I, Murphy K, Yuille A L. DeepLab: Semantic image segmentation with deep convolutional nets, atrous convolution, and fully connected CRFs. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2018, 40(4): 834−848 doi: 10.1109/TPAMI.2017.2699184
    [23] Liu Y, Cheng M M, Hu X, Wang K, Bai X. Richer convolutional features for edge detection. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2019, 41(8): 1939−1946 doi: 10.1109/TPAMI.2018.2878849
    [24] Gao S, Cheng M M, Zhao K, Zhang X Y, Yang M H, Philip H S T. Res2net: A new multi-scale backbone architecture. IEEE transactions on pattern analysis and machine intelligence, 2019 doi: 10.1109/TPAMI.2019.2938758
    [25] Li H, Xiong P, Fan H, Sun J. DFANet: Deep feature aggregation for real-time semantic segmentation. In: Proceedings of IEEE Computer Vision and Pattern Recognition, LA, USA: IEEE, 2019. pp. 9522−9531.
    [26] Ding H, Jiang X, Shuai B, Liu A Q, Wang G. Semantic segmentation with context encoding and multi-path decoding. IEEE Transactions on Image Processing, 2020, 29: 3520−3533 doi: 10.1109/TIP.2019.2962685
    [27] Andrew M. A quantified study of segmentation techniques on synthetic geological XRM and FIB-SEM images. Computational Geosciences, 2018, 22(6): 1503−1512 doi: 10.1007/s10596-018-9768-y
    [28] 薛维华, 王浩, 刘国权, 冯敏楠, 齐琳, 陈展鹏. 基于图像序列间相似性的晶粒组织图像分割方法. 中国体视学与图像分析, 2015, 20(04): 400−407

    Xue Wei-Hua, Wang Hao, Liu Guo-Quan, Feng Min-Nan, Qi Lin, Chen Zhan-Peng. Segmentation method of grain microstructure based on similarity among image sequence. Chinese Journal of Stereology and Image Analysis, 2015, 20(04): 400−407
    [29] Jiang F, Gu Q, Hao H, Li N, Wang B, Hu X. A method for automatic grain segmentation of multi-angle cross-polarized microscopic images of sandstone. Computers & Geosciences, 2018, 115: 143−153
    [30] Banerjee S, Chakraborti P C, Saha S K. An automated methodology for grain segmentation and grain size measurement from optical micrographs. Measurement, 2019, 140: 142−150 doi: 10.1016/j.measurement.2019.03.046
    [31] Vincent L, Soille P. Watersheds in digital spaces: An efficient algorithm based on immersion simulations. IEEE Transactions on Pattern Analysis and Machine Intelligence, 1991, 13(6): 583−598 doi: 10.1109/34.87344
    [32] Dollár P, Zitnick C L. Fast edge detection using structured forests. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2015, 37(8): 1558−1570 doi: 10.1109/TPAMI.2014.2377715
    [33] Jobson D J, Rahman Z, Woodell G A. Properties and performance of a center/surround retinex. IEEE transactions on image processing, 1997, 6(3): 451−462 doi: 10.1109/83.557356
    [34] Jobson D J, Rahman Z, Woodell G A. A multiscale retinex for bridging the gap between color images and the human observation of scenes. IEEE Transactions on Image Processing, 1997, 6(7): 965−976 doi: 10.1109/83.597272
    [35] Jackway P T. Gradient watersheds in morphological scale-space. IEEE Transactions on Image Processing, 1996, 5(6): 913−921 doi: 10.1109/83.503908
    [36] Yu Z, Feng C, Liu M Y, Ramalingam S. Casenet: Deep category-aware semantic edge detection. In: Proceedings of IEEE Computer Vision and Pattern Recognition, Honolulu, USA: IEEE, 2017. 5964−5973.
    [37] Liu Y, Lew M S. Learning relaxed deep supervision for better edge detection. In: Proceedings of IEEE Computer Vision and Pattern Recognition, NV, USA: IEEE, 2016. 231−240.
    [38] Liu G, Zhang Y, Wang A. Incorporating adaptive local onformation onto fuzzy clustering for image segmentation. IEEE Transactions on Image Processing, 2015, 24(11): 3990−4000 doi: 10.1109/TIP.2015.2456505
    [39] Grady L. Random walks for image segmentation. IEEE Transactions on Pattern Analysis & Machine Intelligence, 2006, 28(11): 1768−1783
    [40] Lei T, Jia X, Liu T, Liu S, Meng H, Nandi A K. Adaptive morphological reconstruction for seeded image segmentation. IEEE Transactions on Image Processing, 2019, 28(11): 5510−5523 doi: 10.1109/TIP.2019.2920514
    [41] Arbelaez P, Maire M, Fowlkes C, Malik J. Contour detection and hierarchical image segmentation. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2011, 33(5): 898−916 doi: 10.1109/TPAMI.2010.161
    [42] Meila M. Comparing clusterings: an axiomatic view. In: Proceedings of the International Conference on Machine Learning, Bonn, Germany: IMLS, 2005. 577−584.
    [43] Martin D, Fowlkes C, Tal D, Malik J. A database of human segmented natural images and its application to evaluating segmentation algorithms and measuring ecological statistics. In: Proceedings of International Conference on Computer Vision. BC, Canada: IEEE, 2001. 416−423.
    [44] Freixenet J, Muñoz X, Raba D, Martí J, Cufí X. Yet another survey on image segmentation: Region and boundary information integration. In: Proceedings of the European Conference on Computer Vision, Copenhagen, Denmark: IEEE, 2002. 408−422.
