摘要: 设计了高阶全驱系统的一种无模型控制器. 首先, 将无模型控制问题转化为不确定系统的输出反馈半全局镇定问题; 随后, 基于参量Lyapunov设计方法, 构造基于观测器的动态输出反馈. 进一步地, 阐明由原系统与观测器误差系统构成的增广闭环系统是一类弱耦合互联系统, 通过分析该系统特性, 完成闭环系统渐近稳定性与吸引域分析. 最后, 论证该输出反馈控制器构成高阶全驱系统的无模型控制器. 与传统基于模型的控制器相比, 所设计控制器不仅能够适应系统存在未建模动态及控制增益未知的情形, 还具有显式表达式, 且参数调节简便(对于n阶系统, 仅需调整3个参数). 通过船舶航向控制系统与柔性关节机械臂系统的仿真, 验证所设计无模型控制器的有效性.
-
关键词:
- 无模型控制器 /
- 高阶全驱系统 /
- 参量Lyapunov设计 /
- 输出反馈 /
- PD反馈
Abstract: A model-free controller for high-order fully actuated (HOFA) systems is designed. First, the model-free control problem is transformed into a semi-global output feedback stabilization problem for uncertain systems. Next, an observer-based dynamic output feedback controller is derived via parametric Lyapunov design. Furthermore, the resulting augmented closed-loop system, composed of the original system and the observer error system, is shown to be weakly coupled and interconnected. Then, a rigorous analysis confirms the asymptotic stability and region of attraction of the closed-loop system. Finally, the output feedback controller is proven to be a verifiable model-free solution for the HOFA system. Compared to model-based alternatives, the proposed controller handles unmodeled dynamics and unknown control gains, offers an explicit analytical expression, and simplifies parameter tuning to only three parameters for an $n$-th order system. Simulations on ship course control and a flexible-joint robot confirm its effectiveness. -
图 3 柔性关节机械臂(22)的仿真结果
Fig. 3 Simulation results for the flexible-joint manipulator (22)
图 4 转化后系统(23)的状态及估计
Fig. 4 States of the transformed system (23) and their estimations
表 1 P和$ Q(\gamma) $的显式解
Table 1 Explicit solutions for P and $ Q(\gamma) $
系统阶数 A b c P $ Q(\gamma) $ $ n=1 $ 0 1 1 1 γ $ n=2 $ $ \left[\begin{array}{*{20}{c}} {0}&{1}\\{0}&{0 }\end{array} \right] $ $ \left[\begin{array}{*{20}{c}} {0}\\{1} \end{array} \right] $ $ \left[\begin{array}{*{20}{c}} {1}\\{0 }\end{array} \right] ^{{\rm{T}}} $ $ \left[\begin{array}{*{20}{c}} {1}&{1}\\{1}&{2 }\end{array} \right] $ $ \left[\begin{array}{*{20}{c}} {2\gamma}&{\gamma ^{2}}\\{\gamma ^{2}}&{\gamma ^{3} }\end{array} \right] $ $ n=3 $ $ \left[\begin{array}{*{20}{c}} {0}&{I_{2}}\\{0}&{0_{1\times 2} }\end{array} \right] $ $ \left[\begin{array}{*{20}{c}} {0}\\{0}\\{1 }\end{array} \right] $ $ \left[\begin{array}{*{20}{c}} {1}\\{0}\\{0 }\end{array} \right] ^{{\rm{T}}} $ $ \left[\begin{array}{*{20}{c}} {1}&{2}&{1}\\{2}&{5}&{3}\\{1}&{3}&{3 }\end{array} \right] $ $ \left[\begin{array}{*{20}{c}} {3\gamma}&{3\gamma ^{2}}&{\gamma ^{3}}\\{3\gamma ^{2}}&{5\gamma ^{3}}&{2\gamma ^{4}}\\{\gamma ^{3}}&{2\gamma ^{4}}&{\gamma ^{5} }\end{array} \right] $ $ n=4 $ $ \left[\begin{array}{*{20}{c}} {0}&{I_{3}}\\{0}&{0_{1\times 3}} \end{array} \right] $ $ \left[\begin{array}{*{20}{c}} {0}\\{0}\\{0}\\{1} \end{array} \right] $ $ \left[\begin{array}{*{20}{c}} {1}\\{0}\\{0}\\{0} \end{array} \right] ^{{\rm{T}}} $ $ \left[\begin{array}{*{20}{c}} {1}&{3}&{3}&{1}\\{3}&{10}&{11}&{4}\\{3}&{11}&{14}&{6}\\{1}&{4}&{6}&{4 }\end{array} \right] $ $ \left[\begin{array}{*{20}{c}} {4\gamma}&{6\gamma^{2}}&{4\gamma^{3}}&{\gamma^{4}}\\{6\gamma^{2}}&{14\gamma^{3}}&{11\gamma^{4}}&{3\gamma^{5}}\\{4\gamma^{3}}&{11\gamma^{4}}&{10\gamma^{5}}&{3\gamma^{6}}\\{\gamma^{4}}&{3\gamma^{5}}&{3\gamma^{6}}&{\gamma^{7}} \end{array} \right] $ $ \vdots $ $ \vdots $ $ \vdots $ $ \vdots $ $ \vdots $ $ \vdots $
下载: 导出CSV
表 2 船舶航向控制系统的参数
Table 2 Parameters of the ship course control system
参数 $T$ $K$ $\alpha_{1}$ $\alpha_{2}$ $\alpha_{3}$ 数值 1 a 0.25/s 0.01 s2/rad2 0.2 s/rad 0.3
下载: 导出CSV
表 3 柔性关节机械臂的参数
Table 3 Parameters of the flexible-joint manipulator
参数 G K m L $ J_{1} $ $ J_{2} $ 数值 9.8 m/s2 3 N m/rad 0.2 kg 0.2 m 2 kg m2 5 kg m2
下载: 导出CSV
-
[1] Qin Z, Jiang L, Liu T, Jiang Z P. Distributed optimization for uncertain Euler-Lagrange systems with local and relative measurements. Automatica, 2022, 139: 110113 doi: 10.1016/j.automatica.2021.110113 [2] Su H, Wu Y, Zhang L, Chen X. Structure-free containment control for uncertain underactuated multiple Euler-Lagrange systems. Science China Information Sciences, 2023, 66(11): 212203 doi: 10.1007/s11432-022-3711-1 [3] 段广仁. 高阶系统方法–-I. 全驱系统与参数化设计. 自动化学报, 2020, 46(7): 1333−1345 doi: 10.16383/j.aas.c200234Duan Guang-Ren. High-order system approaches: Ⅰ. Fully-actuated systems and parametric designs. Acta Automatica Sinica, 2020, 46(7): 1333−1345 doi: 10.16383/j.aas.c200234 [4] 段广仁. 高阶系统方法–-Ⅱ. 能控性与全驱性. 自动化学报, 2020, 46(8): 1571−1581Duan Guang-Ren. High-order system approaches: Ⅱ. Controllability and full-actuation. Acta Automatica Sinica, 2020, 46(8): 1571−1581 [5] 段广仁. 高阶系统方法–-Ⅲ. 能观性与观测器设计. 自动化学报, 2020, 46(9): 1885−1895Duan Guang-Ren. High-order system approaches: Ⅲ. Observability and observer design. Acta Automatica Sinica, 2020, 46(9): 1885−1895 [6] Duan G R. High-order fully actuated system approaches: Part Ⅱ. Generalized strict-feedback systems. International Journal of Systems Science, 2021, 52(3): 437−454 doi: 10.1080/00207721.2020.1829168 [7] Duan G R. Fully actuated system approach for control: An overview. IEEE Transactions on Cybernetics, 2024, 54(12): 7285−7306 doi: 10.1109/TCYB.2024.3457584 [8] Byrnes C I, Isidori A. Asymptotic stabilization of minimum phase nonlinear systems. IEEE Transactions on Automatic Control, 1991, 36(10): 1122−1137 doi: 10.1109/9.90226 [9] Song Y, Wang Y, Holloway J, Krstic M. Time-varying feedback for regulation of normal-form nonlinear systems in prescribed finite time. Automatica, 2017, 83: 243−251 doi: 10.1016/j.automatica.2017.06.008 [10] 陈志翔, 高钦和, 谭立龙, 董家臣. 基于非线性扩张状态观测器的直线电机PD控制. 国防科技大学学报, 2018, 40(6): 151−156 doi: 10.11887/j.cn.201806021Chen Zhi-Xiang, Gao Qin-He, Tan Li-Long, Dong Jia-Chen. PD controller for linear motors via nonlinear extended state observer. Journal of National University of Defense Technology, 2018, 40(6): 151−156 doi: 10.11887/j.cn.201806021 [11] Orlov Y, Kairuz R I V, Aguilar L T. Prescribed-time robust differentiator design using finite varying gains. IEEE Control Systems Letters, 2021, 6: 620−625 doi: 10.1109/lcsys.2021.3084134 [12] Zemouche A, Boutayeb M. On LMI conditions to design observers for Lipschitz nonlinear systems. Automatica, 2013, 49(2): 585−591 doi: 10.1016/j.automatica.2012.11.029 [13] Tsinias J. A theorem on global stabilization of nonlinear systems by linear feedback. Systems & Control Letters, 1991, 17(5): 357−362 doi: 10.1016/0167-6911(91)90135-2 [14] Wang X, Park J H. State-based dynamic event-triggered observer for one-sided Lipschitz nonlinear systems with disturbances. IEEE Transactions on Circuits and Systems Ⅱ: Express Briefs, 2022, 69(4): 2326−2330 doi: 10.1109/TCSII.2022.3141769 [15] Li S L, Zhou B, Shi Y, Duan G R. Prescribed-time semi-global control for a class of nonlinear uncertain systems by linear time-varying feedback. IEEE Transactions on Cybernetics, 2025, 55(3): 1172−1182 doi: 10.1109/TCYB.2024.3498838 [16] Chen H, Jia X, Xiang C. Global output feedback control for uncertain nonlinear systems with input quantisation and sensor gain perturbation. International Journal of Control, 2025, 98(10): 2265−2274 doi: 10.1080/00207179.2024.2403474 [17] Hou Z, Xiong S. On model-free adaptive control and its stability analysis. IEEE Transactions on Automatic Control, 2019, 64(11): 4555−4569 doi: 10.1109/TAC.2019.2894586 [18] 李中奇, 周靓, 杨辉. 高速动车组数据驱动无模型自适应控制方法. 自动化学报, 2023, 49(2): 437−447Li Zhong-Qi, Zhou Liang, Yang Hui. Data-driven model-free adaptive control method for high-speed electric multiple unit. Acta Automatica Sinica, 2023, 49(2): 437−447 [19] Clarke D W, Mohtadi C, Tuffs P S. Generalized predictive control—Part I. The basic algorithm. Automatica, 1987, 23(2): 137−148 doi: 10.1016/0005-1098(87)90087-2 [20] 吴卓睿, 张萌, 管晓宏. 面向电力系统快速频率响应的数据与模型驱动预测控制. 自动化学报, 2025, 51(10): 2337−2346 doi: 10.16383/j.aas.c250261Wu Zhuo-Rui, Zhang Meng, Guan Xiao-Hong. Data and model-driven predictive control for fast frequency response in power systems. Acta Automatica Sinica, 2025, 51(10): 2337−2346 doi: 10.16383/j.aas.c250261 [21] 韩京清. 自抗扰控制器及其应用. 控制与决策, 1998, 13(1): 19−23Han Jing-Qing. Auto-disturbances rejection controller and it's applications. Control and Decision, 1998, 13(1): 19−23 [22] Chen S, Chen Z X, Huang Y, Zhao Z L. New design of active disturbance rejection control for nonlinear uncertain systems with unknown control input gain. Science China Information Sciences, 2022, 65(4): 142201 doi: 10.1007/s11432-020-3121-3 [23] 黄一. 关于自抗扰控制的稳定性分析. 控制理论与应用, 2024, 41(8): 1501−1505Huang Yi. Stability analysis of active disturbance rejection control. Control Theory & Applications, 2024, 41(8): 1501−1505 [24] Teel A R, Praly L. Tools for semiglobal stabilization by partial state and output feedback. SIAM Journal on Control and Optimization, 1995, 33(5): 1443−1488 doi: 10.1137/S0363012992241430 [25] Gauthier J P, Hammouri H, Othman S. A simple observer for nonlinear systems applications to bioreactors. IEEE Transactions on Automatic Control, 1992, 37(6): 875−880 doi: 10.1109/9.256352 [26] Khalil H K, Esfandiari F. Semiglobal stabilization of a class of nonlinear systems using output feedback. IEEE Transactions on Automatic Control, 1993, 38(9): 1412−1415 doi: 10.1109/9.237658 [27] Atassi A N, Khalil H K. A separation principle for the stabilization of a class of nonlinear systems. IEEE Transactions on Automatic Control, 1999, 44(9): 1672−1687 doi: 10.1109/9.788534 [28] Mousavi S, Guay M. A low-power multi-high-gain observer design for a class of nonlinear systems. IEEE Transactions on Automatic Control, 2024, 69(9): 6405−6412 doi: 10.1109/TAC.2024.3388255 [29] Levant A. Robust exact differentiation via sliding mode technique. Automatica, 1998, 34(3): 379−384 doi: 10.1016/S0005-1098(97)00209-4 [30] Guo B, Zhao Z. On convergence of tracking differentiator. International Journal of Control, 2011, 84(4): 693−701 doi: 10.1080/00207179.2011.569954 [31] Fossen T I. Guidance and Control of Ocean Vehicles. Hoboken, New Jersey, USA: Wiley, 1994. 33−38 [32] Rsetam K, Cao Z, Man Z. Design of robust terminal sliding mode control for underactuated flexible joint robot. IEEE Transactions on Systems, Man, and Cybernetics: Systems, 2022, 52(7): 4272−4285 doi: 10.1109/TSMC.2021.3096835 [33] H. K. Khalil, Nonlinear systems (Third edition). Upper Saddle River, New Jersey: Prentice Hall, 2002. 108−109 [34] Zhou B, Shi Y. Prescribed-time stabilization of a class of nonlinear systems by linear time-varying feedback. IEEE Transactions on Automatic Control, 2021, 66(12): 6123−6130 doi: 10.1109/TAC.2021.3061645 [35] Li S L, Zhou B, Duan G R. Semiglobal output feedback control for uncertain minimum-phase nonlinear systems. Science China Information Sciences, 2026, 66(2): 122201 doi: 10.1007/s11432-024-4518-1 -
