基于视觉特征提示的跨类别航天器关键点检测方法

周栋; 马炜钊; 孙光辉; 胡瑀晖; 贺子鹏; 张兵

doi:10.16383/j.aas.c250472

基于视觉特征提示的跨类别航天器关键点检测方法

doi: 10.16383/j.aas.c250472 cstr: 32138.14.j.aas.c250472

周栋^{1, 2,},
马炜钊^{1, 2,},
孙光辉^{1, 2,},
胡瑀晖^{1, 2,},
贺子鹏^3,,
张兵^4,

1.
哈尔滨工业大学航天学院哈尔滨 150001
2.
自主智能无人系统工信部重点实验室哈尔滨 150001
3.
中国空间技术研究院北京 100089
4.
深空探测实验室合肥 230031

基金项目: 国家自然科学基金青年科学基金项目(62403162)资助

详细信息

作者简介:
周栋：哈尔滨工业大学航天学院副研究员. 2023年获得哈尔滨工业大学控制科学与工程系博士学位. 主要研究方向为空间视觉感知, 具身智能与深度强化学习.E-mail: dongzhou@hit.edu.cn

马炜钊：哈尔滨工业大学航天学院硕士研究生. 2024年获得西南交通大学学士学位. 主要研究方向为航天器视觉位姿估计. E-mail: weizhaoma@stu.hit.edu.cn

孙光辉：哈尔滨工业大学航天学院教授. 2010年获得哈尔滨工业大学控制科学与工程系博士学位. 主要研究方向为空间机器人视觉、轨迹规划与柔顺控制. 本文通信作者.E-mail: guanghuisun@hit.edu.cn

胡瑀晖：哈尔滨工业大学航天学院博士研究生. 2022年获得哈尔滨工业大学航天学院控制科学与工程系硕士学位. 主要研究方向为航天器视觉位姿估计与空间机器人轨迹规划. E-mail: huyuhui@hit.edu.cn

贺子鹏：中国空间技术研究院助理工程师. 主要研究方向为航天器视觉位姿估计. E-mail: hzp_rocket@163.com

张兵：深空探测实验室助理工程师. 主要研究方向为智能深空探测.E-mail: bz154964@gmail.com

计量
- 文章访问数: 8
- HTML全文浏览量: 5
- 被引次数: 0
出版历程
- 网络出版日期: 2026-03-16

Cross-category Spacecraft Keypoints Detection Method with Visual Feature Prompts

ZHOU Dong^{1, 2
,},
MA Wei-Zhao^{1, 2
,},
SUN Guang-Hui^{1, 2
,},
HU Yu-Hui^{1, 2
,},
HE Zi-Peng^3
,,
Zhang Bing^4
,

1.
School of Astronautics, Harbin Institute of Technology, Harbin 150001
2.
Key Laboratory of Autonomous Intelligent Unmanned Systems of MIIT, Harbin 150001
3.
China Academy of Space Technology, Beijing 100089
4.
Deep Space Exploration Laboratory, Hefei 230031

Funds: Supported by National Natural Science Foundation of China for Young Scientists Project (62403162)

More Information

Author Bio:
ZHOU Dong Associate Professor at the School of Astronautics, Harbin Institute of Technology. He received his Ph.D. degree from the Department of Control Science and Engineering, Harbin Institute of Technology in 2023. His research interests include space visual perception, embodied intelligence and deep reinforcement learning

MA Wei-Zhao Master student at the School of Astronautics, Harbin Institute of Technology. He received his bachelor degree from the Southwest Jiaotong University in 2024. His main research interest is spacecraft visual pose estimation

SUN Guang-Hui Professor at the School of Astronautics, Harbin Institute of Technology. He received his Ph.D. degree from the Department of Control Science and Engineering, Harbin Institute of Technology in 2010. His research interests include space robotic vision, trajectory planning and compliance control. Corresponding author of this paper

HU Yu-Hui Ph.D. candidate at the School of Astronautics, Harbin Institute of Technology. He received his master degree in Control Science and Engineering from the School of Astronautics, Harbin Institute of Technology, in 2022. His research interests include spacecraft visual pose estimation and space robot trajectory planning

HE Zi-Peng Assistant Engineer at the China Academy of Space Technology. His main research interest is spacecraft visual pose estimation

ZHANG Bing Assistant Engineer of the Deep Space Exploration Laboratory. His main research interest is intelligent deep space exploration

摘要

摘要: 航天器视觉位姿估计是空间智能在轨服务的技术核心, 其往往采用关键点检测与位姿解算相结合的两阶段方案. 然而, 现有的航天器关键点检测方法通常利用单一航天器的视觉图像数据进行训练, 因此, 它们无法适用于其他类型的航天器目标, 这严重限制了空间在轨服务的推广与应用. 为此, 提出一种基于视觉特征提示的跨类别航天器关键点检测方法. 当针对未知类别的新目标航天器时, 该方法仅需要给定一张支持图像和对应的关键点提示, 便可以准确预测出目标航天器关键点在查询图像中的位置. 为进一步验证所提方法的有效性, 依托虚拟仿真平台构建一个包含多种航天器、二维关键点标注以及三维姿态标注的多航天器位姿估计数据集. 在该数据集上进行的大量实验结果表明, 所提方法在跨类别航天器关键点检测任务中表现出色, 显著优于当前主流的关键点检测方法. 此外, 该方法与传统PnP算法相结合, 可以实现对任意航天器的高精度位姿估计. 本文方法的代码和数据集均已开源, 详见https://github.com/Dongzhou-1996/CSKDet.
- 航天器位姿估计 /
- 航天器关键点检测 /
- 视觉特征提示 /
- 两阶段位姿估计 /
- 多航天器位姿估计数据集
Abstract: Spacecraft visual pose estimation is the technical core of intelligent on-orbit services, often implemented through a two-stage approach that combines keypoint detection and pose solver. However, existing spacecraft keypoint detection methods are typically trained using visual data from a single spacecraft, making them inapplicable to other types of spacecraft targets. This significantly hinders the promotion and application of space on-orbit services. To address this issue, this paper proposes a cross-category spacecraft keypoint detection method based on visual feature prompts, named as CSKDet (cross-category spacecraft keypoints detector). When applied to a new target spacecraft of an unknown category, this method only requires one support image and its corresponding keypoint annotations to accurately predict the positions of the target spacecraft's keypoints in a query image. To further validate the effectiveness of the proposed method, a spacecrafts pose estimation (SPE) dataset, was constructed using a virtual simulation platform. This dataset includes various types of spacecraft, annotated with 2D keypoints and 3D pose labels. Extensive experiments conducted on this dataset demonstrate that the proposed method excels in cross-category spacecraft keypoint detection tasks, significantly outperforming current mainstream keypoint detection approaches. Moreover, when combined with traditional PnP algorithms, this method enables high-precision pose estimation for arbitrary spacecraft. The code and dataset of this method have been open-sourced at https://github.com/Dongzhou-1996/CSKDet.
- Spacecraft visual pose estimation /
- Spacecraft keypoints detection /
- Visual feature prompt /
- Two-stage pose estimation /
- Spacecrafts Pose Estimation Dataset

HTML全文

图 1 CSKDet整体架构

Fig. 1 The overall architecture of the CSKDet method

下载: 全尺寸图片幻灯片

图 2 SPE数据集中航天器关键点的定义

Fig. 2 The definition of keypoints of spacecraft in the SPE dataset

下载: 全尺寸图片幻灯片

图 3 关键点检测可视化图

Fig. 3 The visualization diagram of keypoints detection

下载: 全尺寸图片幻灯片

图 4 CSKDet在SPEED数据集上的检测效果

Fig. 4 The keypoints detection results of CSKDet on SPEED dataset

下载: 全尺寸图片幻灯片

表 1 不同视觉传感器的特点比较

Table 1 The Characteristics comparison of different visual sensors

视觉传感器	观测距离	能量消耗	感知精度	硬件成本
激光雷达	远	高	高	高
单目相机	中	低	低	低
双目相机	中	中	高	中
RGB-D相机	近	中	中	中
RGB-T相机	近	中	中	高

下载: 导出CSV

表 2 CSKDet的训练超参数

Table 2 The training hyperparameters of CSKDet

参数	值
输入图像尺寸	256像素 × 256像素
关键点热力图尺寸	64像素 × 64像素
支持图像数目	1, 3, 5
编码器	ResNet50
残差解码层层数	3层
优化器	AdamW
余弦退火周期	20轮
初始学习率	0.005
骨干网络冻结训练轮次	60轮
骨干网络解冻训练轮次	20轮
解冻后学习率	0.001

下载: 导出CSV

表 3 航天器关键点检测评估结果

Table 3 The evaluation results of spacecraft keypoints detection

方法	1号航天器	2号航天器	3号航天器	4号航天器	平均估计误差
HRNet^[25]	68.88	70.04	70.67	70.33	69.99
ResUNet^[26]	5.86	38.29	33.99	32.39	25.42
CSKDet ($K$=1)	11.25	28.34	25.16	19.02	19.02
CSKDet ($K$=3)	9.35	27.63	24.23	14.25	17.52
CSKDet ($K$=5)	7.33	25.27	17.51	11.95	14.17

下载: 导出CSV

表 4 航天器位姿估计评估结果

Table 4 The evaluation results of spacecraft pose estimation

方法	1号航天器		2号航天器		3号航天器		4号航天器		平均值
	位置误差	姿态误差	位置误差	姿态误差	位置误差	姿态误差	位置误差	姿态误差	位置误差	姿态误差
	(无量纲)	(rad)	(无量纲)	(rad)	(无量纲)	(rad)	(无量纲)	(rad)	(无量纲)	(rad)
HRNet^[25]	3.34	2.21	5.82	2.33	2.48	2.74	3.57	2.18	3.59	2.36
ResUNet^[26]	0.02	0.14	0.31	1.11	0.18	1.07	0.18	0.85	0.15	0.72
DMANet^[30]	1.13	0.99	2.63	1.82	1.40	2.74	3.02	2.10	2.05	1.91
CSKDet(K=1)	0.04	0.23	0.19	0.68	0.17	0.72	0.06	0.35	0.10	0.46
CSKDet(K=3)	0.03	0.21	0.15	0.66	0.15	0.67	0.05	0.30	0.09	0.43
CSKDet(K=5)	0.02	0.16	0.12	0.54	0.09	0.48	0.04	0.24	0.06	0.33

下载: 导出CSV

表 5 消融实验结果

Table 5 The ablation study results

方法	平均估计误差
原始CSKDet($K$=3)	17.52
去除视觉特征提示模块	36.95
去除交叉融合层	28.36
1层残差解码器	24.55

下载: 导出CSV

表 6 模型算力消耗情况

Table 6 The computational cost of models

方法	平均估计误差	参数量 (MB)	推理时间 (ms)
HRNet^[25]	69.99	28.54	22.83
ResUNet^[26]	25.42	97.28	7.52
CSKDet($K$=1)	19.02	109.65	25.85
CSKDet($K$=3)	17.52	109.65	49.01
CSKDet($K$=5)	14.17	109.65	64.28

下载: 导出CSV
